Specification
| Item | Parameters | Specification |
| Interface | PON Port | 1*XPON port, FSAN G.984.2 standard/IEEE802.3ah Downstream Data Rate：2.488Gbps Upstream Data Rate：1.244Gbps SC/UPC single mode fiber 28dB Link loss and 20KM distance with 1:128 Receiving sensitivity:≤-30dBm Transmitting optical power:0~+4dBm |
| Ethernet Port(LAN) | 1*GE Auto-negotiation RJ45 ports Full Duplex / Half-Duplex RJ45, Auto-MDI/MDI-X Transmission Distance 100 Meter | |
| Power Supply Port | 12V DC input | |
| Management | NetworkManagement | Standard compliant OMCI interface as defined by ITU-T G.984.4 Support WEB management |
| Management Function | Status monitor, Configuration management, Alarm management, Log management | |
| Environmental Specifications | Shell | Plastic casing |
| Power | External 12V 0.5ADC power supply adapter Power consumption: <3W | |
| Dimensions | 110mm(L) x100mm(W) x23mm (H) 0.3kg | |
| Environment | Operating Temperature：0～50℃ StorageTemperature：-40～85℃ Operating Humidity：10%～90%(Non-condensing) StorageHumidity：10%～90%(Non-condensing) |
